PP thermally conductive plastic
0.8W RenJie® TCP100--01 Polypropylene Thermal Plastic
Model: TCP100-01PP
RenJie ® TCP100-01PP is a PP thermally conductive plastic material independently developed by Shenzhen Renjie Plastic Raw Materials Co., Ltd.. The polymer matrix material is uniformly filled with a thermally conductive filler to improve its thermal conductivity. The thermal conductivity is mainly measured by the thermal conductivity (unit: W/m.k). It has the characteristics of uniform heat dissipation, avoiding burning spots, and reducing local deformation of parts due to high temperature. It is generally used in LED lamps and led LCD TV displays.
| Product Description | Polypropylene Thermal Plastic |
|---|---|
| RenJie®Grade | TCP100--01PP |
| Dielectric Breakdown Voltage | >10000 VAC |
| Dielectric Constant, 1MHz | 1MHz |
| Flame retardancy | V-0 |
| Specific Gravity (g/cm³) | 1.55 |
RenJie ® TCP100-01PP is a PP thermally conductive plastic material independently developed by Shenzhen Renjie Plastic Raw Materials Co., Ltd.. The polymer matrix material is uniformly filled with a thermally conductive filler to improve its thermal conductivity. The thermal conductivity is mainly measured by the thermal conductivity (unit: W/m.k). It has the characteristics of uniform heat dissipation, avoiding burning spots, and reducing local deformation of parts due to high temperature. It is generally used in LED lamps and led LCD TV displays.
RenJie®TCP100-01PP —Application
Typical application targets for this grade include RenJie ® TCP100-01PP can be used in applications such as Heat Sinking Housing at LED-lit BLU in LCD/LED TV and LED-lit lamps such as MR16. Also it can replace the normal Aluminum heat sink..
RenJie®TCP100-01PP — Features
- Good thermal conductivity
- Excellent thermal conductivity compared to normal engineering plastics
- Lighter than normal Aluminum housing 30% in weight
- Excellent mould ability in injection moulding
| Parameter | Value (typical / as stated) | Method / note |
|---|---|---|
| Physical Properties | ||
| Color | White | Visual |
| Melt index | 14.73 g/10min | ASTM D1238 |
| Specific Gravity (g/cm³) | 1.55 | ASTM D792 |
| Shrinkage | 1.3 % | ASTM D955 |
| Mechanical Properties | ||
| Tensile Strength | 9.92 MPa | ASTM D638 |
| Flexural Strength | 38 MPa | ASTM D790 |
| Flexural Modulus | 3900 MPa | ASTM D790 |
| Impact Strength, notched | 8.9 kJ/m² | GB/T 1483-2008 |
| Electrical Properties | ||
| Dielectric Breakdown Voltage | >10000 VAC | ASTM D149 |
| Dielectric Constant, 1MHz | 3.1 | ASTM D150 |
| Volume Resistivity (Ω·m) | 7.0 × 10¹² | ASTM D257 |
| Thermal Properties | ||
| Heat Deflection Temperature | 130 °C | ASTM D648 |
| Thermal Conductivity Through Plane (W/m·K) | 0.8 | ASTM E1461 |
| Flame retardancy | V-0 Class | Min. thick. 1.0mm |
| Injection parameters | ||
| Barrel Zone Temperature — One sect | 180–220°C | — |
| Barrel Zone Temperature — Two sect | 190–230°C | — |
| Barrel Zone Temperature — Three sect | 180–220°C | — |
| Mouth Temperature | 200–230°C | — |
| Melt Temperature | 200–240°C | — |
| Bake Temperature | 80–90°C 2H | — |
| Mould Temperature | According to the machine tonnage °C | — |
| Injection Pressure | According to the machine tonnage Bar | — |
| Injection Speed | Medium Speed mm/s | — |
* Match values to the PDF revision cited on your purchase order.
| Product Description | Polypropylene Thermal Plastic |
|---|---|
| RenJie®Grade | TCP100--01PP |
| Dielectric Breakdown Voltage | >10000 VAC |
| Dielectric Constant, 1MHz | 1MHz |
| Flame retardancy | V-0 |
| Specific Gravity (g/cm³) | 1.55 |
| Thermal Conductivity Through Plane (W/m·K) | 0.8W/m-K |
| Volume Resistivity (Ω·m) | 7.0 × 10¹² |
| Base Polymer | Polypropylene(PP) |
| Color | 颗粒/灰白色 |
| Melt index | 14.73g/10min |
| Shrinkage | 1.3% |
| Tensile strength | 9.92 MPa |
| Flexural strength | 38 MPa |
| Flexural modulus | 3900 MPa |
| Impact Strength | 8.9 J/m |
